CHASSIS

- 265-

CHECKING THE OIL COOLER

1. Check:

• oil cooler

Obstruction

Clean.

Apply compressed air to the rear of the oil

cooler.

Damage

Repair or replace the oil cooler.

NOTE:

Straighten any flattened fins with a thin,

flathead screwdriver.

2. Check:

• oil pipes

Cracks/damage

Replace.
