ENGINE
- 156 -
PRIMARY AND SECONDARY SHEAVES
No. Part Name Qty Remarks
Removing the primary and secondary
sheaves
Remove the parts in the order listed.
Engine assembly
1 Drive belt cover 1
2 Rubber gasket 1
3 V-belt 1
4 Secondary fixed sheave 1
5 Secondary sliding sheave 1
6 Compression spring 1
7 Guide Base, Driven Gear 1
8 Driving Flyweight 1
9 Primary fixed sheave 1
10 Compression spring/Spring seat 1/1
To Next Page
