CHASSIS

- 257-

COOLING SYSTEM

RADIATOR

No. Part Name Qty Remarks

Removing the radiator

1 Cooler, water-tank 1

2 Water tank assembly 1

3 Rubber cushion, water tank 2

4 Bolt,flange M8×12 2

5 Fan assembly 1

6 Water inlet rubber pipe 1

7 Pipe clip 2
