CHASSIS
- 270-
DISASSEMBLING THE WATER PUMP
1. Remove:
• rubber damper holder ①
• rubber damper ②
NOTE:
Do not scratch the impeller shaft.
2. Remove:
• water pump seal ①
• Water pump housing②
NOTE:
Tap out the water pump seal from the inside of
the water pump housing.
3. Remove:
• bearing ①
• oil seal ②
•water pump housing ③
NOTE:
• Tap out the bearing and oil seal from the
outside of the water pump housing.
• Apply lithium-soap-based grease to the oil
seal and apply engine oil to the bearing.
