ENGINE

- 157 -

No. Part Name Qty Remarks

11 Spacer 1

12 Fixing Base, One-Way Bearing 1

13 Guide pin/spring 1/1

14 Primary sliding sheave 1

15 Drive belt case 1

16 O-ring 2

For assembly, reverse the disassembly

procedure.
