CHASSIS

- 195-

DISK BRAKE COMPONENTS

No. Part Name Qty Remarks

9 Bolt ,flange M6×20 8

Oil pipe clip Ⅱ, front disc brake

Disc brake assembly ((Front & Rear/dual

disk brake)

12 Front disc brake oil pipe assembly 1
