CHASSIS

- 206-

No. Part Name

Qty Remarks

18 Parking brake case 1

19 Gasket 1

20 Bleed screw 1

21 Brake caliper bracket 1

22 Caliper piston seal 1

23 Dust seal 1

24 Brake caliper piston 1
