Hisun HS800UTV - Page 242

To Next Page

To Previous Page

CHASSIS

- 228-

No. Part Name Qty Remarks

42 Rubber rectangular ring, cap seal 1

43 Bolt M10×1.25×80 2

44 Bolt M10×1.25 2

45 Circlip 2

46 Cushion piece 2

47 Spring D=Φ25×Φ2.3×28 2

48 Dustproof rubber cover 2

49 Dowel pin 1

50 Clip 1
