CHASSIS

- 227-

No. Part Name Qty Remarks

31 Sensor assy-speed 1

32 Induction coil assembly 1

33 Circlip 106.5×1.2 1

34 Adjustment gasket 1

35 Screw M5×18 1

36 O-ring 1

37 Front bridge differential assembly 1

38 Adjustment column 1

39 Tube 1

40 Clip 1

41 Universal joint 1
