CHASSIS
- 226-
No. Part Name Qty Remarks
21 Joint cross shaft 1
22
Connection fork Ⅱ
1
23 Transmission shaft, front bridge 1
24 Retainer fixed plate 1
25 O-ring, oil inlet (outlet) bolt 2
26 Oil outlet bolt, front bridge 1
27 Rectangular ring, front bridge box 1
28 Bolt M8×25 11
29 Drive gear bush 1
30 Gascket 1
