SPECIFICATIONS
- 67-
Item Standard Limit
Shifter
Shifter type
Shift drum and guide bar
----
Air filter oil grade Engine oil ----
Oil pump
Oil filter type
Oil pump type
Tip clearance
Side clearance
Body clearance
Bypass valve setting pressure
Oil pressure (hot)
Pressure check location
Chartaceous
Trochoid
0.15 mm
(0.0059 in)
0.03 ~ 0.10 mm
(0.0012 ~ 0.0039 in)
0.09 ~ 0.17 mm
(0.0035 ~ 0.0067 in)
441.0 ~ 637.0 Kpa
(4.41 ~ 6.37 kg/cm2, 62.7 ~ 90.6 psi)
65 Kpa (0.65 kg/cm2, 9.2 psi)
at 1,500 r/min
Cylinder head
----
---
----
----
----
----
----
----
----
----
----
----
----
Water pump
Type
Reduction ratio
Single-suction centrifugal pump
15/15 (1.0)
----
----
Shaft drive
Middle gear backlash
Final gear backlash
Differential gear backlash
0.1 ~ 0.3 mm (0.004 ~ 0.012 in)
0.1 ~ 0.3 mm (0.004 ~ 0.012 in)
0.05 ~ 0.25 mm(0.002 ~ 0.010 in)
----
----
----
Cooling system
Radiator core
Width
Height
Thickness
Radiator cap opening pressure
Radiator capacity
(including all routes)
Coolant reservoir
Capacity
From low to full level
380 mm (14.96 in)
238 mm (9.37 in)
24 mm (0.94 in)
107.9 ~ 137.3 Kpa
(1.079~1.373 kg /cm2, 15.35~19.53 psi)
2.5 L (2.20 Imp qt, 2.64 US qt)
0.35 L (0.31 Imp qt, 0.37 US qt)
0.20 L (0.15 Imp qt, 0.21 US qt)
----
----
----
----
----
----
----
