ENGINE

- 177 -

No. Part Name Qty Remarks

11 BearingⅠ 1

12 L gear driven gear 1

13 H gear driven gear 1

14 Needle bearing 1

15 R gear driven gear 1

16 Bearing Ⅱ 1

17 R shaft transmission assembly 1

18 Reverse shaft 1

19 R gear idle gear/ R gear idle gear shaft 1/1

For assembly, reverse the disassembly

procedure.
