MAINTENCE AND ADJUSTMENT OF THE UTV
- 124 -
b. If the tester indicates“∞”, replace the fuse.
3. Replace:
a. Turn off the ignition.
b. Install a new fuse of the proper amperage.
c. Turn on switches to verify operation of the
related electrical devices.
d. If the fuse immediately blows again, check the
electrical circuit.
Description
Current
rating
Quantity
Main 30 A 1
Lighting
system fuse
15 A 1
Ignition 10 A 1
Terminal
(Auxiliary DC jack)
10 A 1
4WD(Four wheel
drive)
3 A 1
Signaling
system fuse
10 A 1
Carburetor
heater fuse
10 A 1
Backup fuse 10 A 1
Reserve 30 A 1
Reserve 15 A 1
Reserve 10 A 1
Reserve 3 A 1
WARNING
:
Ever use a fuse with a rating other than that
specified. Never use other materials in place of a
fuse. An improper fuse may
cause extensive
damage to the electrical
system, a malfunction
of the lighting and
ignition systems and could
possibly cause a fire.
.
