ENGINE
- 173 -
• shims ①
• universal joint yoke
• washer
• nut ①
NOTE:
Use the universal joint holder ② to hold the
yoke.
• universal joint.
a. Install the opposite yoke into the universal
joint.
b. Apply wheel bearing grease to the bearings.
c. Install the bearing ① onto the yoke.
CAUTION:
Check each bearing. The needles can easily
fall out of their races. Slide the yoke back
and forth on the bearings; the yoke will not
go all the way onto a bearing if a needle is
out of place.
a. Press each bearing into the universal joint
using a suitable socket.
NOTE:
The bearing must be inserted far enough into
the universal joint so that the circlip can be
installed.
e. Install the circlip ② into the groove of each
bearing.
• drive shaft coupling
• washer
• nut ①
NOTE:
Use the coupling gear/middle shaft tool ②
to hold the drive shaft coupling.
