CHASSIS

- 240-

No. Part Name Qty Remarks

Gearshift comp 1

12 Rear bracket, gearshift cable 1

13 Bolt M6×25 2

14 Gearshift rocker pivot 1

15 Bolt M6×20 1

16 Gearshift cable assembly 1

17 Nut ,Self-locked M6 2

18 Draining tube 1

19 Clip 2

20 Plug, draining tube 1

21 Bolt M610×1.25×35 1

22 Washer 1
