CHASSIS

- 253-

No. Part Name Qty Remarks

10 Nut, self-locking M10x1.25 2

11 Middle bushing 4

12 Nut, self-locking M10x1.25 4

13 Bolt, flange M10×1.25×102 2

14 Nut, self-locking M10x1.25 2

15 Bolt, flange M10×1.25×70 4

16 Washer 8

17 Curved nozzle M6 2
