CHASSIS

- 259-

No. Part Name Qty Remarks

18 Pipe clip(rubber covered) 4

19 Bolt ,flange M6×12 4

20 Standby water bottle 1

21 Bolt ,flange M6×16 2

22 Connection rubber pipe, standby water tank 1

23 Clip 2

24 Standby water tank cover assembly 1

25 Overflow pipe 1

26 Clip 1

27 H-type rubber ring 2
