CHASSIS

- 267-

No. Part Name Qty Remarks

Removing the water pump

1 water pump housing cover 1

2 Water pump assembly 1

3 Bolt M6×40 3

4 Washer Φ6×Φ10×1 1

5 Bolt M6×65 1

6 Secondary gear,water pump 1

7 Transmission shaft,water pump 1

8 Pin Φ4×21 1

9 Circlip Φ10 1
