CHASSIS
- 274-
No. Part Name Qty Remarks
9 Left slide rail assembly, seat 2
10 Bolt M8×30 10
11 Seat lower mounting board 2
12 Bolt, flange M6×16 4
13 Nut ,flange nylex M6 8
14 Left lock combination 1
15 Bolt, flange M10×1.25×22 2
16 Safety belt component 2
17 Left safety belt assembly (Tri-Point fixing style) 1
To Next Page
