CHASSIS
- 279-
No. Part Name Qty Remarks
12 Bolt ,flange M8×45 2
13 Fuel tank rubber cushion 36×26×5 9
14 Electronic fuel pump 1
15
Oil tank outlet pipe Ⅱ
3
16
Oil tank outlet pipeⅠ
1
17 Tee joint 1
18 Pipe clip Φ10-Φ20 9
19 Oil cleaner, high pressure element assembly 1
20 Negative pump plate 1
21 Nut, flange nylex M6 6
22 Oil seal, electronic fuel pump 1
23 Shock absorbtion rubber, fuel pump 4
24
Connector Ⅱ
1
