Honeywell Fusion4 MSC-L User Manual

Installation - Fusing and Power Consumption
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 14 Installation & Operation Manual
Honeywell
FIGURE 4-4 illustrates the block schematic of a zero ohm resistor on
the MSC-SHORTCUT-BOARD.
FIGURE 4-4 Block schematic of a zero ohm resistor on the MSC-SHORTCUT-BOARD
SSR
SSR1_Feed_AC
SSR1_Feed_AC
SSR1_SW_AC
AC_FUSED_1
0 Ω
Resistor
AC_IN
AC_Neutral
4 pin connector for field connection
4 pin connector for Shortcut board
48 pin connector for CAN-ARM or
CAN-IN-OUT board
SSR1_SW_AC
