Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 4 - 29
DO-SSR-AC 30 CAN-ARM-MSC-2 DO-SSR-30
CN-211 8 DO-SSR-AC 31 CAN-ARM-MSC-2 Orange N-5 DO-SSR-31
DO-SSR-AC 32 CAN-ARM-MSC-2 DO-SSR-32
CN-212 8 DO-SSR-AC 33 CAN-IN-OUT-MSC-3 Orange N-4 DO-SSR-33
DO-SSR-AC 34 CAN-IN-OUT-MSC-3 DO-SSR-34
CN-213 8 DO-SSR-AC 35 CAN-IN-OUT-MSC-3 Orange N-3 DO-SSR-35
DO-SSR-AC 36 CAN-IN-OUT-MSC-3 DO-SSR-36
CN-214 8 DO-SSR-AC 37 CAN-IN-OUT-MSC-4 Orange N-2 DO-SSR-37
DO-SSR-AC 38 CAN-IN-OUT-MSC-4 DO-SSR-38
CN-215 8 DO-SSR-AC 39 CAN-IN-OUT-MSC-4 Orange N-1 DO-SSR-39
DO-SSR-AC 40 CAN-IN-OUT-MSC-4 DO-SSR-40
CN-216 4 DI-AC 7 CAN-IN-OUT-MSC-3 Red T-5 DI-AC-7
DI-AC 8 CAN-IN-OUT-MSC-3 DI-AC-8
DI-AC 9 CAN-IN-OUT-MSC-3 DI-AC-9
CN-217 4 DI-AC 10 CAN-IN-OUT-MSC-4 Red T-4 DI-AC-10
DI-AC 11 CAN-IN-OUT-MSC-4 DI-AC-11
DI-AC 12 CAN-IN-OUT-MSC-4 DI-AC-12
CN-218 6 DI-DC 31 CAN-IN-OUT-MSC-3 Green C-11 DI-DC-31
DI-DC 32 CAN-IN-OUT-MSC-3 DI-DC-32
DI-DC 33 CAN-IN-OUT-MSC-3 DI-DC-33
CN-219 6 DI-DC 34 CAN-IN-OUT-MSC-3 Green C-10 DI-DC-34
DI-DC 35 CAN-IN-OUT-MSC-3 DI-DC-35
DI-DC 36 CAN-IN-OUT-MSC-3 DI-DC-36
CN-220 6 DI-DC 37 CAN-IN-OUT-MSC-3 Green C-9 DI-DC-37
DI-DC 38 CAN-IN-OUT-MSC-3 DI-DC-38
DI-DC 39 CAN-IN-OUT-MSC-3 DI-DC-39
CN-221 6 DI-DC 40 CAN-IN-OUT-MSC-3 Green C-8 DI-DC-40
DI-DC 41 CAN-IN-OUT-MSC-3 DI-DC-41
DI-DC 42 CAN-IN-OUT-MSC-3 DI-DC-42
CN-222 6 DI-DC 43 CAN-IN-OUT-MSC-3 Green C-7 DI-DC-43
ID PINS FUNCTIONS BOARD COLOR X-Y NAME
