Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 30 Installation & Operation Manual
Honeywell
DI-DC 44 CAN-IN-OUT-MSC-3 DI-DC-44
DI-DC 45 CAN-IN-OUT-MSC-3 DI-DC-45
CN-223 6 DI-DC 46 CAN-IN-OUT-MSC-4 Green G-11 DI-DC-46
DI-DC 47 CAN-IN-OUT-MSC-4 DI-DC-47
DI-DC 48 CAN-IN-OUT-MSC-4 DI-DC-48
CN-224 6 DI-DC 49 CAN-IN-OUT-MSC-4 Green G-10 DI-DC-49
DI-DC 50 CAN-IN-OUT-MSC-4 DI-DC-50
DI-DC 51 CAN-IN-OUT-MSC-4 DI-DC-51
CN-225 6 DI-DC 52 CAN-IN-OUT-MSC-4 Green G-9 DI-DC-52
DI-DC 53 CAN-IN-OUT-MSC-4 DI-DC-53
DI-DC 54 CAN-IN-OUT-MSC-4 DI-DC-54
CN-226 6 DI-DC 55 CAN-IN-OUT-MSC-4 Green G-8 DI-DC-55
DI-DC 56 CAN-IN-OUT-MSC-4 DI-DC-56
DI-DC 57 CAN-IN-OUT-MSC-4 DI-DC-57
CN-227 6 DI-DC 58 CAN-IN-OUT-MSC-4 Green G-7 DI-DC-58
DI-DC 59 CAN-IN-OUT-MSC-4 DI-DC-59
DI-DC 60 CAN-IN-OUT-MSC-4 DI-DC-60
CN-228 3 AI 8 CAN-ARM-MSC-2 Green A-11 AI-8
CN-229 3 AI 9 CAN-ARM-MSC-2 Green A-10 AI-9
CN-230 3 AI 10 CAN-ARM-MSC-2 Green A-9 AI-10
CN-231 3 AI 11 CAN-ARM-MSC-2 Green A-7 AI-11
CN-232 3 AI 12 CAN-ARM-MSC-2 Green A-6 AI-12
CN-233 3 AI 13 CAN-ARM-MSC-2 Green A-5 AI-13
CN-234 3 AI 14 CAN-ARM-MSC-2 Green C-5 AI-14
CN-235 6 QPI-A 7 CAN-ARM-MSC-2 Green C-6 QPI-7A
QPI-B 7 CAN-ARM-MSC-2 QPI-7B
CN-236 6 QPI-A 8 CAN-ARM-MSC-2 Green F-5 QPI-8A
QPI-B 8 CAN-ARM-MSC-2 QPI-8B
CN-237 6 QPI-A 9 CAN-ARM-MSC-2 Green F-4 QPI-9A
QPI-B 9 CAN-ARM-MSC-2 QPI-9B
CN-238 6 QPI-A 10 CAN-ARM-MSC-2 Green G-6 QPI-10A
QPI-B 10 CAN-ARM-MSC-2 QPI-10B
CN-239 6 QPI-A 11 CAN-ARM-MSC-2 Green J-5 QPI-11A
QPI-B 11 CAN-ARM-MSC-2 QPI-11B
CN-240 6 QPI-A 12 CAN-ARM-MSC-2 Green J-4 QPI-12A
QPI-B 12 CAN-ARM-MSC-2 QPI-12B
ID PINS FUNCTIONS BOARD COLOR X-Y NAME
