Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 72 Installation & Operation Manual
Honeywell
CN-209
1 DO-SSR-27 F SSr27_feed_ac Feed High frequency,
fast switching
AC output
control.
Actuator outputs
Additive solenoid
Additive injection
feedback
Alarm shutdown
Alarm indication
Pump start
Additive blocking
valve
2 DO-SSR-27 O SSr27_sw_ac Signal - Output
3 DO-SSR-27 N N Neutral
4 DO-SSR-27 L L Live
5 DO-SSR-28 F SSr28_feed_ac Feed
6 DO-SSR-28 O SSr28_sw_ac Signal - Output
7 DO-SSR-28 N N Neutral
8 DO-SSR-28 L L Live
CN-210
1 DO-SSR-29 F SSr29_feed_ac Feed High frequency,
fast switching
AC output
control.
Actuator outputs
Additive solenoid
Additive injection
feedback
Alarm shutdown
Alarm indication
Pump start
Additive blocking
valve
2 DO-SSR-29 O SSr29_sw_ac Signal - Output
3 DO-SSR-29 N N Neutral
4 DO-SSR-29 L L Live
5 DO-SSR-30 F SSr30_feed_ac Feed
6 DO-SSR-30 O SSr30_sw_ac Signal - Output
7 DO-SSR-30 N N Neutral
8 DO-SSR-30 L L Live
CN-211
1 DO-SSR-31 F SSr31_feed_ac Feed High frequency,
fast switching
AC output
control.
Actuator outputs
Additive solenoid
Additive injection
feedback
Alarm shutdown
Alarm indication
Pump start
Additive blocking
valve
2 DO-SSR-31 O SSr31_sw_ac Signal - Output
3 DO-SSR-31 N N Neutral
4 DO-SSR-31 L L Live
5 DO-SSR-32 F SSr32_feed_ac Feed
6 DO-SSR-32 O SSr32_sw_ac Signal - Output
7 DO-SSR-32 N N Neutral
8 DO-SSR-32 L L Live
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
