Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 4 - 73
CN-212
1 DO-SSR-33 F SSr33_feed_ac Feed High frequency,
fast switching
AC output
control.
Actuator outputs
Additive solenoid
Additive injection
feedback
Alarm shutdown
Alarm indication
Pump start
Additive blocking
valve
2 DO-SSR-33 O SSr33_sw_ac Signal - Output
3 DO-SSR-33 N N Neutral
4 DO-SSR-33 L L Live
5 DO-SSR-34 F SSr34_feed_ac Feed
6 DO-SSR-34 O SSr34_sw_ac Signal - Output
7 DO-SSR-34 N N Neutral
8 DO-SSR-34 L L Live
CN-213
1 DO-SSR-35 F SSr35_feed_ac Feed High frequency,
fast switching
AC output
control.
Actuator outputs
Additive solenoid
Additive injection
feedback
Alarm shutdown
Alarm indication
Pump start
Additive blocking
valve
2 DO-SSR-35 O SSr35_sw_ac Signal - Output
3 DO-SSR-35 N N Neutral
4 DO-SSR-35 L L Live
5 DO-SSR-36 F SSr36_feed_ac Feed
6 DO-SSR-36 O SSr36_sw_ac Signal - Output
7 DO-SSR-36 N N Neutral
8 DO-SSR-36 L L Live
CN-214
1 DO-SSR-37 F SSr37_feed_ac Feed High frequency,
fast switching
AC output
control.
Actuator outputs
Additive solenoid
Additive injection
feedback
Alarm shutdown
Alarm indication
Pump start
Additive blocking
valve
2 DO-SSR-37 O SSr37_sw_ac Signal - Output
3 DO-SSR-37 N N Neutral
4 DO-SSR-37 L L Live
5 DO-SSR-38 F SSr38_feed_ac Feed
6 DO-SSR-38 O SSr38_sw_ac Signal - Output
7 DO-SSR-38 N N Neutral
8 DO-SSR-38 L L Live
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
