Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 74 Installation & Operation Manual
Honeywell
CN-215
1 DO-SSR-39 F SSr39_feed_ac Feed High frequency,
fast switching
AC output
control.
Actuator outputs
Additive solenoid
Additive injection
feedback
Alarm shutdown
Alarm indication
Pump start
Additive blocking
valve
2 DO-SSR-39 O SSr39_sw_ac Signal - Output
3 DO-SSR-39 N N Neutral
4 DO-SSR-39 L L Live
5 DO-SSR-40 F SSr40_feed_ac Feed
6 DO-SSR-40 O SSr40_sw_ac Signal - Output
7 DO-SSR-40 N N Neutral
8 DO-SSR-40 L L Live
CN-216
1 DI-AC-7, 8,
9
N AC_NEUTRAL Neutral AC input control Programmable
inputs
ESD input
2 DI-AC-7 7-L AC7_L Live
3 DI-AC-8 8-L AC8_L Live
4 DI-AC-9 9-L AC9_L Live
CN-217
1 DI-AC-10,
11, 12
N AC_NEUTRAL Neutral AC input control Programmable
inputs
ESD input
2 DI-AC-10 10-L AC10_L Live
3 DI-AC-11 11-L AC11_L Live
4 DI-AC-12 12-L AC12_L Live
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
