Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 4 - 75
CN-218
1 DI-DC-31 H DC31_hi Signal - Input DC input control Programmable
inputs
ESD input
2 DI-DC-31 C COMMON Common
3 DI-DC-32 H DC32_hi Signal - Input
4 DI-DC-32 C COMMON Common
5 DI-DC-33 H DC33_hi Signal - Input
6 DI-DC-33 C COMMON Common
CN-219
1 DI-DC-34 H DC34_hi Signal - Input DC input control Programmable
inputs
ESD input
2 DI-DC-34 C COMMON Common
3 DI-DC-35 H DC35_hi Signal - Input
4 DI-DC-35 C COMMON Common
5 DI-DC-36 H DC36_hi Signal - Input
6 DI-DC-36 C COMMON Common
CN-220
1 DI-DC-37 H DC37_hi Signal - Input DC input control Programmable
inputs
ESD input
2 DI-DC-37 C COMMON Common
3 DI-DC-38 H DC38_hi Signal - Input
4 DI-DC-38 C COMMON Common
5 DI-DC-39 H DC39_hi Signal - Input
6 DI-DC-39 C COMMON Common
CN-221
1 DI-DC-40 H DC40_hi Signal - Input DC input control Programmable
inputs
ESD input
2 DI-DC-40 C COMMON Common
3 DI-DC-41 H DC41_hi Signal - Input
4 DI-DC-41 C COMMON Common
5 DI-DC-42 H DC42_hi Signal - Input
6 DI-DC-42 C COMMON Common
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
