Installation - Wiring Termination Guidance
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 4 - 81
CN-240
1 QPI-12A 12 V 12 V DC
METER
POWER
Power High frequency
pulse input
control +
external power
Additive flow
meter (single or
dual)
Product flow meter
(single or dual
pulse).
2 QPI-12A C COMMON Common
3 QPI-12A P PULSE A Pulse Signal -
Input A
4 QPI-12B 12 V 12 V DC
METER
POWER
Power
5 QPI-12B C COMMON Common
6 QPI-12B P PULSE B Pulse Signal -
Input B
CN-241
1 RTD-4 S- RTD S- Three wire
connection
Resistance
Temperature
Detector input
control
Preferred: PT100
temperature
measurement
according to IEC
60751.
2 RTD-4 C RTD COM Neutral
3 RTD-4 A RTD POS Signal - Input
4 RTD-4 S+ RTD S+ Four wire
connection
CN-242
1 RTD-5 S- RTD S- Three wire
connection
Resistance
Temperature
Detector input
control
Preferred: PT100
temperature
measurement
according to IEC
60751.
2 RTD-5 C RTD COM Neutral
3 RTD-5 A RTD POS Signal - Input
4 RTD-5 S+ RTD S+ Four wire
connection
CN-243
1 RTD-6 S- RTD S- Three wire
connection
Resistance
Temperature
Detector input
control
Preferred: PT100
temperature
measurement
according to IEC
60751.
2 RTD-6 C RTD COM Neutral
3 RTD-6 A RTD POS Signal - Input
4 RTD-6 S+ RTD S+ Four wire
connection
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
