Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 82 Installation & Operation Manual
Honeywell
CN-244
1 PO-3 HI Po3_HI Feed Pulse output
control
2 PO-3 LO Po3_LO Signal - Output
3 PO-4 HI Po4_HI Feed
4 PO-4 LO Po4_LO Signal - Output
CN-245
1 AO-5 + AO_a5 Signal - Output
(+)
Analog output
control
2 AO-5 - AO_b5 Signal - Output
(-)
3 AO-6 + AO_a6 Signal - Output
(+)
4 AO-6 - AO_b6 Signal - Output
(-)
5 AO-4 + AO_a4 Signal - Output
(+)
6 AO-4 - AO_b4 Signal - Output
(-)
CN-246
1 COM-6 + RS485_A_CH6 Receive RS485
communication
interface (2-wire)
Preferred interface
to:
TAS
Fusion4 Portal
Smart Additive
2 COM-6 - RS485_B_CH6 Transmit
3 COM-6 C RS485_Commo
n_CH6
0 V
4 COM-7 + RS485_A_CH7 Receive
5 COM-7 - RS485_A_CH7 Transmit
6 COM-7 C RS485_Commo
n_CH7
0 V
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
