J41 AIRCRAFT CONFIGU-
RATION:
1. AFIS Key - DEPRESS, if
necessary, to display the
AFIS MENU Page. See
Figure 8-15.
2. Line Select Key -
DEPRESS to position the
cursor over WGT/BAL.
3. ENTER Key - DEPRESS.
WGT/BAL Page is dis-
played. See Figure 8-16.
4. Line Select Key -
DEPRESS to position the
cursor in PAX A field, left
side.
5. INSERT the number of
passengers in the left side
of zone A. The input range
for each of the two entries
is 0-5. The sum of adults
plus children must not
exceed 5 for the zone.
6. ENTER Key - DEPRESS.
The cursor automatically moves to the PAX A right side field.
7. INSERT the number of passengers in the right side of zone A.
8. ENTER Key - DEPRESS. The cursor automatically moves to the
PAX B left side field if the total number of passengers for zone A
does not exceed the limit. The left and right fields will blink if the
total count is exceeded. The input range for each of the two
entries in zone B, C, D and E is 0-6. The sum of adults plus
children must not exceed 6 for the zone.
9. Repeat Steps 4 through 8 for each zone. After the input for PAX
E is complete, the cursor will be located in the FWDCL field.
10. INSERT The number of carry-on bags in the forward closet.
11. ENTER Key - DEPRESS. The cursor moves to the JUMP field
12. INSERT a 1 if the jumpseat is being occupied, or leave blank.
8-17
GNS-XLS FMS with Regional Airline AFIS
Rev 4
Sep/97
>
WGT/BAL INITIALIZE
STATION DVT/HOLD
WEATHER CLOSE OUT
DISPATCH
SEND MSG
DISPLAY MSG
20:09 AFIS MENU
<
><
<
< >
<
Figure 8-15
PAX A 2/ AFT CK
PAX B / POD CO
PAX C / AFT LB
PAX D / POD LB
PAX E / FUEL
FWDCL TAXI
JUMP BURN
FA10A NO FA
TRANSMIT
20:11 WGT
&
BAL
<
><
<
< >
<
>
>
>
Figure 8-16
