HP Integrity rx6600 Service Manual

Table 60 I/O Card Events That May Light Diagnostic Panel LEDs (continued)
NotesSourceCauseSample IPMI EventsDiagnostic
LEDs
Either a card / slot
problem. Reseat card first.
SFWPCI slot’s standby
power failed
Type E0h, 147d:26d
IO_SLOT_STANDBY_POWER_ERROR
I/O Card
Either a card / slot
problem. Reseat card first
SFWPCI-X hot-plug controller
failed
Type E0h, 131d:26d
IO_HOT_PLUG_CTRL_FAILED
I/O Card
Remove any unsupported
I/O cards. Move I/O
card to an unused PCI slot
SFWPCI bus walk (I/O
discovery) resources
exceeded
Type E0h, 139d:26d
IO_PCI_MAPPING_TOO_BIG
I/O Card
SFWFound invalid PCIXCAP
value
Type E0h, 148d:26d
IO_UNKNOWN_PCIXCAP_VAL
I/O Card
SFWPCIXCAP sampling
error
Type E0h, 141d:26d
IO_PCIXCAP_SAMPLE_ERROR
I/O Card
SFWExpected I/O host
bridge (Lower Bus
Adapter) is missing
Type E0h, 123d:26d
IO_CHECK_LBA_MISSING_ERR
I/O Card
SFWExpected I/O host
bridge (Lower Bus
Type E0h, 619d:26d
IO_CHECK_LBA_DECONFIG_ERR
I/O Card
Adapter) is
deconfigured
SFWI/O LBA clear error
failed
Type E0h, 133d:26d
IO_LBA_CLEAR_ERR_FAILED
I/O Card
SFWI/O SBA clear error
failed
Type E0h, 144d:26d
IO_SBA_CLEAR_ERR_FAILED
I/O Card
SFWPCI-X slot power on
error
Type E0h, 146d:26d
IO_SLOT_POWER_ON_ERROR
I/O Card
SFWPCI-X slot has incorrect
default power state
Type E0h, 145d:26d
IO_SLOT_POWER_DEFAULT_ERROR
I/O Card
SFWI/O host bridge (Lower
Bus Adapter) is
Type E0h, 136d:26d
IO_LBA_RESET_ERROR
I/O Card
inaccessible because
rope reset failed to
complete
SFWPCI clock DLL errorType E0h, 130d:26d IO_DLL_ERRORI/O Card
SFWI/O rope reset failed to
complete
Type E0h, 143d:26d
IO_ROPE_RESET_ERROR
I/O Card
Table 61 lists the PCI slot-rope-acpi paths.
Table 61 PCI/PCI-X Slot-Rope-ACPI Paths
Logical ACPI PathOLARDPhysical Rope #Physical Slot #
Acpi(HWP0002,PNP0A03,0)/Pci(1 |0)
Acpi(HWP0002,PNP0A03,0)/Pci(1 | 1)
No0XX
Slow core iLO 2 MP at 33MHz.
Acpi(HWP0002,PNP0A03,0)/Pci(1 | 2)
Acpi(HWP0002,PNP0A03,0)/Pci(2 | 0)
Acpi(HWP0002,PNP0A03,0)/Pci(2 | 1)
Acpi(HWP0002,PNP0A03,0)/Pci(2 | 2)
Acpi(HWP0002,PNP0A03,400)/Pci(1 | 0)No81
Fast core storage at 66 MHz.
Common I/O Backplane (LBAs/Ropes/PDH/PCI-X Slots) 165
