Table 61 PCI/PCI-X Slot-Rope-ACPI Paths (continued)
Logical ACPI PathOLARDPhysical Rope #Physical Slot #
Acpi(HWP0002,PNP0A03,400)/Pci(2 | 0)
Acpi(HWP0002,PNP0A03,400)/Pci(2 | 1)
No82
Fast core LAN at 66 MHz.
Acpi(HWP0002,PNP0A03,700)/Pci(1 | 0)Yes12, 13, 14 &
15
3
Public, single at 266 MHz.
Acpi(HWP0002,PNP0A03,300)/Pci(1 | 0)Yes4, 5, 6 & 74
Public, single at 266 MHz.
Acpi(HWP0002,PNP0A03,600)/Pci(1 | 0)Yes10 & 115
Public, single at 133 MHz.
Acpi(HWP0002,PNP0A03,200)/Pci(1 | 0)Yes2 & 36
Public, single at 133 MHz.
Acpi(HWP0002,PNP0A03,500)/Pci(1 | 0)Yes97
Public, shared at 66 MHz.
Acpi(HWP0002,PNP0A03,500)/Pci(2 | 0)Yes98
Public, shared at 66 MHz.
Acpi(HWP0002,PNP0A03,100)/Pci(1 | 0)Yes19
Public, shared at 66 MHz.
Acpi(HWP0002,PNP0A03,100)/Pci(2 | 0)Yes110
Public, shared at 66 MHz.
Table 62 PCI/PCI-X/PCIe Slot-Rope-ACPI Paths
Logical ACPI PathOLARD
Physical Rope
#Physical Slot #
Acpi(HWP0002,PNP0A03,0)/Pci(1|*)No0XX
Slow core iLO 2 MP at
33MHz.
Acpi(HWP0002,PNP0A03,0)/Pci(2|*)No0XX
Core I/O USB
Acpi(HWP0002,PNP0A03,0)/Pci(4|*)No0XX
Core I/O VGA (optional)
Acpi(HWP0002,PNP0A03,400)/Pci(1|*)No81
Fast core storage at 66
MHz.
Acpi(HWP0002,PNP0A03,400)/Pci(2|*)No82
Fast core LAN at 66 MHz.
Acpi(HPQ0002,PNP0A08,600)/Pci(0|0)/Pci(0|0)/Pci(1|0)/Pci(0|*)
1
No10 & 113
Public, switched daul x8
Acpi(HPQ0002,PNP0A08,600)/Pci(0|0)/Pci(0|0)/Pci(0|0)/Pci(0|*)
1
No10 & 114
Public, switched dual x8
Acpi(HPQ0002,PNP0A08,700)/Pci(0|0)/Pci(0|*)Yes12, 13, 14 &
15
5
Public, single at x8
Acpi(HPQ0002,PNP0A08,300)/Pci(0|0)/Pci(0|*)Yes4, 5, 6 & 76
Public, single at x8
Acpi(HWP0002,PNP0A03,200)/Pci(1|*)Yes2 & 37
Public, single at 133 MHz
Acpi(HWP0002,PNP0A03,500)/Pci(1|*)Yes98
Public, single at 133 MHz
166 Troubleshooting
