13-35

802.1w Rapid Spanning Tree Protocol (RSTP) and 802.1d Spanning Tree Protocol (STP)

802.1p Spanning-Tree Protocol (STP)

Figure 13-17. Example of STP Enabled with Two Redundant Links Configured for

Fast-Uplink STP

5. Press (for Save) to save the configuration changes to flash (non-

volatile) memory.

To View Fast-Uplink STP Status. Continuing from figures 13-16 and 13-17

in the preceding procedure, this task uses the same screen that you would use

to view STP status for other operating modes.

1. From the Main Menu, select:

1. Status and Counters . . .

7. Spanning Tree Information

STP is enabled.

Port A1 and Trk1 are

now configured for

fast-uplink STP.

!Software.book Page 35 Thursday, October 10, 2002 6:10 PM
