HP V1910 User Manual

463
a.
Network diagram for PoE
GE1/0/1
GE1/0/11
GE1/0/2
AP
PSE
Configuration procedure
# Enable PoE on GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2, and set their power supply priority to
critical.
 Select PoE  PoE from the navigation tree and click the Setup tab to perform the following
configurations, as shown in a.
a. Configure the PoE ports supplying power to the IP telephones
 Click to select ports GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2 from the chassis front panel.
 Select Enable from the Power State drop-down list.
 Select Critical from the Power Priority drop-down list.
 Click Apply.
# Enable PoE on GigabitEthernet 1/0/11 and configure the maximum power of the port to 9000 milliwatts.
 Click the Setup tab and perform the following configurations, as shown in b.

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
