Read all safety notices before servicing the system. Observe all safety procedures
when performing a procedure. Unless instructed otherwise, always power off the
system before removing, exchanging, or installing a field-replaceable unit (FRU).
Attention: To prevent overheating problems, do not remove any SPD (book) card
completely from the card enclosure unless you install an airflow card in its place.
DANGER
To prevent a possible electrical shock from touching two surfaces with
different electrical grounds, use one hand, when possible, to connect or
disconnect signal cables. (RSFTD004)
DANGER
To prevent a possible electrical shock during an electrical storm, do not
connect or disconnect cables or station protectors for communications lines,
display stations, printers, or telephones. (RSFTD003)
DANGER
To prevent power from switching on automatically during service procedures,
select manual or secure mode on the system unit control panel or disconnect
the cables that connect to J15 and J16 on the frame being serviced.
(RSFTD211)
Breaking Down The SRC: This table defines the fields of the SRC and their
corresponding Control Panel function. Word 7 of the SRC allows you to determine
the correct Bus number, bus type, multi-adapter bridge number, multi-adapter
bridge function number and logical card number from the Direct Select Address
(DSA). Physical card slot labels and card positions for PCI busses are determined
by using the DSA and the appropriate system unit or expansion tower card
position table. See “Card Position Tables” on page 282.
Table 6. SRC Break Down Table
SRC Word
Control Panel
Function
Panel Function
Characters Format Description
1 11 1-8 B600 uuuu uuuu = unit reference code (69xx)
1-extended SRC
information
11 9-16 iiii Frame ID of the failing resource
1-extended SRC
information
11 17-24 ffff Frame location
1-extended SRC
information
11 25-32 bbbb Board position
2 12 1-8 MIGVEP62 See “Hardware SRC Formats” on page 940
for details.
3 12 9-16 cccc cccc Component reference code
4 12 17-24 pppp pppp Programming reference code
5 12 25-32 qqqq qqqq Program reference code high order
qualifier
6 13 1-8 qqqq qqqq Program reference code low order
qualifier
Bus, High-Speed Link (HSL) PIPs
