Table 19. Processor Configuration Table (continued)
Model Processor
Feature Code
Processor
Capacity Card
CCIN
Interactive Card
CCIN
Proc 0
CCIN
Proc 1
CCIN
Proc 2
CCIN
Proc 3
CCIN
830 23D6 2402 1536 234D
830 23D8 2403 1531 245D 235D
830 23D9 2403 1532 245D 235D
830 23DA 2403 1533 245D 235D
830 23DB 2403 1534 245D 235D
830 23DC 2403 1535 245D 235D
830 23DD 2403 1536 245D 235D
830 23DE 2403 1537 245D 235D
830 26AE 2351 1537 245D 245D
830 26AD 2351 1536 245D 245D
830 26AC 2351 1535 245D 245D
830 26AB 2351 1534 245D 245D
830 26AA 2351 1533 245D 245D
830 26A9 2351 1532 245D 245D
830 26A8 2351 1531 245D 245D
1. Did you come to this Symbolic FRU from a Power procedure (1xxx SRC) or a
B1xx SRC?
No Yes
↓ Go to Step 7 on page 519 of this procedure.
2. Is the type number from the FRU information zero? (Refer to the information
at the beginning of the “(B437) System Processor Reference Codes” on
page 215.)
No Yes
↓ Go to Step 6 on page 519 of this procedure.
3. Use the type number from the FRU information, to determine the Part
Number from the “Type, Model, and Part Number list” on page 885. Then,
continue with step 4 of this procedure.
4. Is the location from the Reference Code Table MB1?
No Yes
↓ The failing item is a backplane. Before exchanging any parts, verify
that the connections to the backplane are secure. Then go to step 10 on
page 519 of this procedure.
5. See the FRU locations and Failing Components table for the system that you
are working on to determine the CCIN and removal and installation
procedure for the location specified. Use the following references:
v For models 830 and SB2 see Table 41 on page 710.
v For models 840 and SB3 see Table 42 on page 720.
Symbolic FRUs
518
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
