Notes:
1. The FC 9074 Base I/O Tower contains two system PCI busses.
2. In the FRU Locations and Failing Components table below, the first of the two
busses in the FC 9074 tower is ″0001″ and the second bus in the tower is
designated as ″yyyy″.
3. In FC 9074 tower the bus connected to card positions C01 - C04 is bus number
0001. The other bus in FC 9074 tower is not required to be in order.
4. Card position C01 is required to be an I/O processor.
5. Card positions C05 and C11 are required to be either I/O processors or
Integrated xSeries Servers (IXS).
6. Multi-adapter Bridge domains are labeled PCI Bridge Set inside the tower.
7. The following table provides information necessary to identify the IOP to
which IOAs are assigned. The left column indicates the domain in which IOA
assignment is allowed. The right column is used to determine the IOP to which
an IOA is assigned. The first position in the list must be an IOP. The remaining
positions may be IOPs or IOAs. IOAs are assigned to the first IOP located to
their left in the list. Although IOAs can be manually reassigned using SST/DST,
the IOA assignments return to the default order after each IPL.
Multi-adapter bridge domain / PCI Bridge
Set
IOA assignment rules
C01 - C04 C01, C02, C03, C04
C05 - C10 C05, C06, C07, C08, C09, C10
C11 - C15 C11, C12, C13, C14, C15
Table 41. FRU Locations and Failing Components Table for Models 830, SB2 System Unit with FC 9074 Base I/O
Tower
Position FRU Name Possible Failing
Component
Type, CCIN, or Part Number
(use the “Type, Model, and
Part Number list” on page 885
to determine the part number
when Type or CCIN are
given.)
Removal and Installation/Recovery
Procedure
MB1 System Unit
Backplane
System Unit Backplane 281A Go to “Models 830/SB2 with FC 9074
– System Unit Backplane (MB1)” on
page 673.
M01 Processor
Regulator
Processor Regulator 27AA or 27AB Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
M02 Memory Riser
Card
Memory Riser Card 2881 Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
M02
(Daughter
Cards)
Memory DIMM See Figure 31 on
page 715.
300F, 3002, 3004, 3005, 3006,
3007
Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
M03 Processor Card Processor 245C or 245D Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
M04 Processor Card Processor 245C or 245D Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
M05 Memory Riser
Card
Memory Riser Card 2881 Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
M05
(Daughter
Cards)
Memory DIMM See Figure 31 on
page 715.
300F, 3002, 3004, 3005, 3006 Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
Locations and Addresses
710
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
