Table 41. FRU Locations and Failing Components Table for Models 830, SB2 System Unit with FC 9074 Base I/O
Tower (continued)
Position FRU Name Possible Failing
Component
Type, CCIN, or Part Number
(use the “Type, Model, and
Part Number list” on page 885
to determine the part number
when Type or CCIN are
given.)
Removal and Installation/Recovery
Procedure
M06 Network
Interface
Controller
(NIC) Card
Network Interface
Controller (NIC)
2732, 2754, 2758, or 2769 Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
M06 Ports Network
Interface
Controller
(NIC) Ports
See Figure 32 on
page 716.
N/A N/A
M06A Clock Card Clock Card 25AB, 25AD Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
M06-C08 HSL Ribbon
Cable
HSL connection
(SIGC73), See “Model
830 and Model SB2 with
FC 9074” on page 780.
See Table 54 on page 781. N/A
PP1 PP2 Power Supply Power Supply 515B Go to “Models 830/SB2 with FC 9074
– Power Supply (PP1 and PP2)” on
page 670.
BP1 BP2 AMD AMD 04N3345 Go to “Models 830/SB2 with FC 9074
– AMD (BP1 and BP2)” on page 654
C01 PCI Card IOP 2842 or 2843 Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
C02 PCI Card The failing component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and Part
Number list” on page 885.
.
Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
C03 PCI Card The failing component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and Part
Number list” on page 885.
Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
C04 PCI Card The failing component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and Part
Number list” on page 885.
Go to “Models 830/SB2 with FC 9074
– Cards – Dedicated” on page 658.
C05 PCI card The failing component is
either an:
1. IOP
2. Integrated xSeries
Server (IXS)
1. 2842 or 2843
2. 2890
Note: When the IXS card
is installed in this position
concurrent maintenance at
the card position is not
recommended.
If IXS, go to “Models 830/SB2 with
FC 9074 – Cards – Dedicated” on
page 658. Otherwise, go to “Models
830/SB2 with FC 9074 – Cards –
Concurrent” on page 655.
C06 PCI Card (if no
IXS in C05)
The failing component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and Part
Number list” on page 885.
Go to “Models 830/SB2 with FC 9074
– Cards – Concurrent” on page 655.
C07 PCI Card IOA See “Type, Model, and Part
Number list” on page 885.
Go to “Models 830/SB2 with FC 9074
– Cards – Concurrent” on page 655.
Locations and Addresses
Chapter 5. Locations, Addresses, and Part Listings 711
