Multi-adapter bridge domain / PCI Bridge
Set
IOA assignment rules
C01 - C04 C01, C02, C03, C04
C05 - C10 (Not including C08) C05, C06, C07, C09, C10
C11 - C15 C11, C12, C13, C14, C15
Table 44. FRU Locations and Failing Components Table for FC 5074 I/O Towers
Position FRU Name Possible Failing
Component
Type, CCIN, or Part
Number (use the “Type,
Model, and Part Number
list” on page 885 to
determine the part number
when Type or CCIN are
given.)
Removal and Installation Procedure
C01 PCI Card IOP 2842 or 2843 Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C02 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C03 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C04 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C05 PCI card The failing
component is
either an:
1. IOP
2. Integrated
xSeries Server
(IXS)
1. 2842 or 2843
2. 2890
Note: When the IXS
card is installed in this
position concurrent
maintenance at the card
position is not
recomended.
If IXS, then go to“FC 5074, FC 5079 –
Cards – Dedicated” on page 622.
Otherwise, go to “FC 5074, FC 5079 –
Cards – Concurrent” on page 620.
C06 PCI Card (if
no IXS in C05)
The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C07 PCI Card IOA See “Type, Model, and Part
Number list” on page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C08 HSL I/O
bridge Card
v High-Speed
Link I/O
Adapter
v PCI Host
Bridge Adapter
2691 Go to “FC 5074, FC 5079 – Cards –
Dedicated” on page 622.
