Table 44. FRU Locations and Failing Components Table for FC 5074 I/O Towers (continued)
Position FRU Name Possible Failing
Component
Type, CCIN, or Part
Number (use the “Type,
Model, and Part Number
list” on page 885 to
determine the part number
when Type or CCIN are
given.)
Removal and Installation Procedure
C09 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C10 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C11 PCI Card The failing
component is
either an:
1. IOP
2. Integrated
xSeries Server
(IXS)
1. 2842 or 2843
2. 2890
Note: When the IXS
card is installed in this
position concurrent
maintenance at the card
position is not
recomended.
If IXS, then go to “FC 5074, FC 5079 –
Cards – Dedicated” on page 622.
Otherwise, go to “FC 5074, FC 5079 –
Cards – Concurrent” on page 620.
C12 PCI Card (if
noIXSinC11)
The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C13 PCI Card IOA See “Type, Model, and Part
Number list” on page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C14 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
C15 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5074, FC 5079 – Cards –
Concurrent” on page 620.
CB1 Tower Card
1. SPCN
2. Card
Enclosure or
Backplane
3. Multi-adapter
Bridge (All)
28AB-97H7307 Go to “FC 5074/5079, FC 9079 –
Tower Card – CB1” on page 635.
B01 - B02 AMD AMD 04N3345 Go to “FC 5074/5079, FC 9074, FC
9079 – AMD – B01 and B02” on
page 619.
Locations and Addresses
738
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
