Table 46. FRU Locations and Failing Components Table for FC 5078, 0578 PCI Expansion Unit (continued)
Position FRU Name Possible
Failing
Component
Type, CCIN, or Part Number
(use the “Type, Model, and
Part Number list” on
page 885 to determine the
part number when Type or
CCIN are given.)
Removal and Installation Procedure
C08 HSL I/O
Bridge Card
v High-Speed
Link I/O
Adapter
v PCI Host
Bridge
Adapter
2691 Go to “FC 5078/0578 – Cards –
Dedicated” on page 649.
C09 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5078/0578 – Cards –
Concurrent” on page 648.
C10 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5078/0578 – Cards –
Concurrent” on page 648.
C11 PCI Card (if
no IXS in
C11)
The failing
component is
either an:
1. IOP
2. Integrated
xSeries
Server
(IXS)
1. 2842 or 2843
2. 2890
Note: When the IXS card
is installed in this
position concurrent
maintenance at the card
position is not
recomended.
Go to “FC 5078/0578 – Cards –
Concurrent” on page 648.
C12 PCI Card (if
no IXS in
C11)
The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5078/0578 – Cards –
Concurrent” on page 648.
C13 PCI Card IOA See “Type, Model, and Part
Number list” on page 885.
Go to “FC 5078/0578 – Cards –
Concurrent” on page 648.
C14 PCI Card The failing
component is
either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type, Model, and
Part Number list” on
page 885.
Go to “FC 5078/0578 – Cards –
Concurrent” on page 648.
C15 PCI Card IOA See “Type, Model, and Part
Number list” on page 885.
Go to “FC 5078/0578 – Cards –
Concurrent” on page 648.
P01 - P02 Power Supply Power Supply 21P4970 Go to “FC 5078/0578 – Power
Supplies – P01 and P02” on page 652.
B01 (AMD
attached to
the power
supply in
location P01)
AMD AMD 41L5448 Go to “FC 5078/0578 – AMDs – B01
and B02” on page 647.
Locations and Addresses
Chapter 5. Locations, Addresses, and Part Listings 745
