Table 46. FRU Locations and Failing Components Table for FC 5078, 0578 PCI Expansion Unit (continued)
Position FRU Name Possible
Failing
Component
Type, CCIN, or Part Number
(use the “Type, Model, and
Part Number list” on
page 885 to determine the
part number when Type or
CCIN are given.)
Removal and Installation Procedure
B02 (AMD
attached to
the power
supply in
location P02)
AMD AMD 41L5448 Go to “FC 5078/0578 – AMDs – B01
and B02” on page 647.
PB1 Power
Distribution
Board
Power
Distribution
Board
00P2382 Go to “FC 5078/0578 – Power
Distribution Backplane – PB1” on
page 651.
NB1 Control Panel Control Panel 247B-24L0962 Go to “FC 5078/0578 – Expansion
Unit Control Panel – NB1” on
page 651.
CB1 Tower Card
1. SPCN
2. Card
Enclosure
or
Backplane
3.
Multi-
adapter
Bridge (All)
28AB-04N6797 Go to “FC 5078/0578 – Tower Card –
CB1” on page 652.
BB1 AMD Control
Card
AMD
Controller
11K1107 Go to “FC 5078/0578 – AMD
Controller Card – BB1” on page 647.
HSL cables on
the HSL ports
HSL cable HSL
connection
See “Type, Model, and Part
Number list” on page 885.
Go to “HSL Cables – Concurrent” on
page 653.
Locations and Addresses
746
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
