idp Smart-30 - Board Parts List

2014-03-24
110
NO CODE NO. ITEM DESCRIPTION PHOTO PAGE
1 630083 MAIN BOARD MAIN BD,SMART,0.57
3.3.1
B.1.4
B.2.10
2 630020 RIBBON RF BOARD RIBBON F BD,SMART,2.0
3.3.2
B.2.4
3 630050 USB HUB BOARD 1 USB HUB BD,SMART,0.1 C.5
4 630096 MS BOARD MS MAIN BD,SMART,0.5 C.1
5 630104 INTERNAL RF BOARD IN_RF_GENDER_30 BD,SMART30,0.1 C.4
6 630070 PCBA-EHTERNET MAIN ASS’Y NETWORK HUB BD EDDY-CPU V2.5-ASSY C.6
A.1 BOARD
A.1 BOARD
