1. Every Roller is fixed by using Bearing or
Bushing on each Main Frame.
2. Disassemble E-Ring on the end of Roller.
3. Disassemble Bearing or Bushing fixed on
Frame. While pushing Roller to Frame
Right Side. Disassemble Left Side of
Roller from Frame.
3.5 Rollers
3.6 Rollers
Cleaning
Roller Fixed
Card In
Roller2
Ms Roller
IC Roller
Printing
Roller
44
Card In
Roller1
To Next Page
