idp Smart-30 - Case Parts List

2014-03-24
114
NO CODE NO. ITEM DESCRIPTION PHOTO PAGE
1 611042
TOP COVER
COVER S3,TOP B.2.11
2 611034 TOP CASE OPEN BUTTON BUTTON S3,TOP B.1.1.3
3 611089 HOPPER COVER ASSY S3,FRONT_COVER B.2.11
4 611040 SIDE COVER R COVER S3,SIDE_R B.2.12
5 611039 SIDE COVER L COVER S3,SIDE_L B.2.12
6 611035 PRINTER BACK COVER COVER S3,BACK B.2.11
7 611039 STACKER COVER S3,STACKER B.2.12
A.5 CASE
A.5 CASE
