idp Smart-30 - Cable Parts List

2014-03-24
112
NO CODE NO. ITEM DESCRIPTION PHOTO PAGE
1 611075 IO CABLE R WIRE,I/O_30 RIGHT,20P,420mm B.1.4
2 611076 IO CABLE L WIRE,I/O_30 LEFT,20P,230mm B.1.4
3 611077 LED CABLE WIRE,LED_30 SW,5P,220mm B.1.4
4 610132 HEAD CABLE WIRE,THERMAL HEAD,26P,370MM B.1.4
5 611078 IC SENSOR CABLE WIRE,IC_30 MOT SEN,6P,210mm C.3
6 610137 RF IN CABLE WIRE,OMNIKEY RF IN USB,170MM,USB1.0 C.4
7 610120 USB CABLE CABLE,USB2AB1.8M,1.8M,USB1.0
1.1.1
B.2.15
A.3 CABLE
A.3 CABLE
