idp Smart-30 - Motor Parts List

2014-03-24
NO CODE NO. ITEM DESCRIPTION PHOTO PAGE
1 630058 RIBBON MOTOR RIBBON MOTOR BD,SMART,0.4 B.2.1
2 630097 HEAD DOWN/UP MOTOR HEAD UD MOTOR_30 BD,SMART30,0.1 B.2.1
3 640264 PRINT STEP MOTOR ASSY S3,STEP_MOTOR
B.1.7
B.2.4
116
A.6 MOTOR
A.6 MOTOR
116
