idp Smart-30 - Sensor Parts List

2014-03-24
111
NO CODE NO. ITEM DESCRIPTION PHOTO PAGE
1 630019
HEAD UP-DOWN SENSOR
SENSOR DETECTOR BD,SMART,0.4
2.1
B.2.1
2 630101 CARD IN_OUT SENSOR SEN_POS_30 BD,SMART30,0.2
2.1
B.2.3
3 630024 COLOR IN SENSOR SENSOR COLOR IN BD,SMART,0.4
2.1
B.1.1.1
4 630026 COLOR OUT SENSOR SENSOR COLOR OUT2 BD,SMART,0.3
2.1
B.2.7
5 630033 ENCODER SENSOR SENSOR ENCODER2 BD,SMART,0.1
2.1
B.2.2
6 630098 CASE ON/OFF SENSOR SEN_CASE_30 BD,SMART30,0.1
2.1
B.2.1
7 630103 IC UP-DOWN SENSOR IC_CAM_SW_30 BD,SMART30,0.2 C.3
A.2 SENSOR
A.2 SENSOR
