idp Smart-30 - Page 170

2014-03-24
170 170
No. IA. CODE NAME Q'TY
1
630096 MS MAIN BD,SMART,0.5
1
2
610355 SCREW SS,M3X6,SAM
1
3
610430 SCREW SS,M3X6,HEX
1
4
610374 WASHER SS,M3_SPRING
1
5
610375 NUT SS,M3X2.4
1
6
610146 FFC CABLE,170mm,16P,0.5mm,2896 c-type
1
 MS HEAD ASSY Assembly
C.1 MS Option
