4.2 Test
In IC tap, the read/write of Smartcard is possible.
“ICH Contact” is the command to contact the head with Smartcard chip. “ICH Discontact” is the dis-contact
command. “Init” is the initialization of the installed IC reader. The installed IC reader will be displayed on right
down control board. “Contact” is contacting between the IC head and Smartcard. “Reset” is stop to use.
After “Contact”, “Get ATR”, “Read”, “Write” and “Clear” command are possible to operate. “Get ATR” is loading ATR
value of Smartcard. “Read” is reading such as name, address, phone data. “Write” is writing.
If read/write the date directly using APDU command, you can use the following APDU command. “Load APDU” is
load the saved APDU command. “Save APDU” is save the current APDU command. “Clear APDU” is clear the APDU
screen. To see the individual APDU command, press “Send APDU” on the line..
To write and read on Smartcard, you have to proceed the following procedure.
Card “IN” → Move “IC” → IC “ICH Contact” → IC “Init” → IC “Contact” → IC “Write” → IC “Clear” → IC “Read” → IC
“Reset” → IC “ICH Dis-contact” → Card “OUT”
If press “Batch Start”, IC encoding will be repeated. SMART Printer is support the internal Smartcard encoder and
external SIM encoder. SIM is not possible to move automatically so the batch is not possible for SIM.
